TAL Series - 1,000 lbs
The TAL Series 1000 lb. capacity, Acme screw linear actuator with adjustable limit switches and a load limiting ball detent clutch is a robust device capable of pushing, pulling, lifting, or lowering loads up to 1000 lbs. The adjustable, integrated limit switches allow precise control of the stroke length. The ball detent design in these clutches provides precise rotary motion with no play, making it ideal for applications requiring exact positioning.
Standard Configurations
Capacity (lbs):
1000
Stroke Length (in):
4, 8, 12, 18
Documents
Need Assistance?
Not sure if this is the right product for your application, or need a custom solution? Contact us today for help from an expert.
Specifications
Specifications
| Model Number | Capacity (lbs) | Duty Cycle at Rated Load (%) | Environment (IP Code) | Input Voltage (VAC) | Input Voltage (VDC) | Lifting Speed at Rated Load (in/s) | Limit Switch | Retracted Length (in) | Stroke Length (in) |
|---|---|---|---|---|---|---|---|---|---|
| TAL10-1A20-12 | 1000 | 0 | IP52 | 115 | 0.43 | Included | 20 | 12 | |
| TAL10-1A20-18 | 1000 | 0 | IP53 | 115 | 0.43 | Included | 24 | 18 | |
| TAL10-1A20-4 | 1000 | 0 | IP50 | 115 | 0.43 | Included | 12 | 4 | |
| TAL10-1A20-8 | 1000 | 0 | IP51 | 115 | 0.43 | Included | 16 | 8 | |
| TAL10-2A20-12 | 1000 | 0 | IP56 | 220 | 0.45 | Included | 20 | 12 | |
| TAL10-2A20-18 | 1000 | 0 | IP57 | 220 | 0.45 | Included | 24 | 18 | |
| TAL10-2A20-4 | 1000 | 0 | IP54 | 220 | 0.45 | Included | 12 | 4 | |
| TAL10-2A20-8 | 1000 | 0 | IP55 | 220 | 0.45 | Included | 16 | 8 |
